- Material
- Bronze
- Compatibility
- Raymarine Axiom DV Raymarine Axiom Pro RVX Raymarine Axiom RV Raymarine CP300 Raymarine CP370 Raymarine DSM30 Raymarine DSM250 Raymarine DSM300 Raymarine RVX-1000
- Frequency
- 50/200 kHz
- Sonar
- CHIRP / Fishfinder
- Model
- B164
- Original Ref.
- A102113
- Maximum depth
- 550 m (maximum depth reading depends on seabed type and other water conditions)
- High-definition scanning
- No
- Scanning the sides of the boat
- No
- 3D Scanning
- No
- Brand
- Raymarine
- Power
- 1 kW
- Mounting type
- Through installation
- Hull angle
- From 16° to 24°.
- For hulls
- Fiberglass Wood
- Displayed data
- Depth Temperature
- Cable length
- 9 m.
- Connector PIN
- 8 pins
- Compatible without adapter
- Raymarine CP300 Raymarine CP370 Raymarine DSM30 Raymarine DSM250 Raymarine DSM300
- Compatible with adapter
- Raymarine Axiom DV with A80485 Raymarine Axiom Pro RVX and Raymarine RVX-1000 with A80496 Raymarine Axiom RV with A80489
- Transducer Tilt (TILT)
- 20°
